Rear cover

REAR SHIELD

Code Action Duration

1 004065 Front shield, rear part - Re-

moval and refitting

2 004023 Shield rim - Replacement

3 004132 Half-panel - replac. (1)

4 004071 Battery compartment - Re-

placement

GP 800 i.e. Time

TIME - 25
