Gilera GP 800 i.e. - Pinion Unit Shaft Bearing Fitting

- Flywheel-side crankcase half:
- Remove the oil seal and the bearing with the
specific tool.
Specific tooling
020376Y Adaptor handle
020662Y Guide 50 mm
020360Y Adaptor 52x54 mm
PINION UNIT SHAFT BEARING FITTING
- The toothed wheel (pinion unit shaft) rotates on
two bearings located on both crankcase halves. To
fit, proceed as follows.
- Transmission-side crankcase half:
- Heat the crankcase using the heat gun.
Specific tooling
020151Y Air heater
- Insert the pinion unit shaft bearing until it stops against the bottom of the seat using the specific tool.
Specific tooling
020376Y Adaptor handle
020363Y 20 mm guide
020359Y 42x47-mm adaptor
- Flywheel-side crankcase half:
- Heat the crankcase using the heat gun.
Specific tooling
020151Y Air heater
Engine GP 800 i.e.
ENG - 30
