Gilera GP 800 i.e. - Pinion Unit Service

- Disimpegnare il pignone dalla catena.
CAUTION
PRESTARE ATTENZIONE CHE I PATTINI DI
TRASCINAMENTO NON CADANO.
PINION UNIT SERVICE
- Fasten the support in a vice.
- Remove both engine-side driving sliders.
N.B.
THE FOUR DRIVING SLIDERS (TWO ON THE SUPPORT SIDE AND TWO ON THE ENGINE SIDE)
ARE INTERCHANGEABLE. MARK THEM SO AS TO RESPECT THE FITTING CLEARANCE CRE-
ATED DURING THE MOVEMENT PHASE.
- Loosen the eight screws fixing the pinion to the
driving bushing from the safety plate.
- Undo the eight screws.
GP 800 i.e. Engine
ENG - 21
