19. Windshield motor: to reach it, remove the front
shield.
20. Roll-over sensor: to reach it, remove the front
shield.
21. Voltage regulator: to reach it, remove the front
shield.
Electric characteristic
Control voltage
14 ÷ 14.7 V at 1000÷8000 rpm
22. Horn: to reach it, remove the front shield.
Ground points
There are three ground points in the electrical system:
Electrical system GP 800 i.e.
ELE SYS - 10
