Gilera GP 800 i.e.

To Next Page

To Previous Page

HT coil

REAR CYLINDER HV COIL CONNECTOR

1. Injection load relay (Black-Green)

2. Control unit (Pink-Black)

GP 800 i.e. Injection

INJEC - 23
