Gilera GP 800 i.e. - Front Central Cover

- Undo the five screws indicated.
- Remove the side fairing by pulling it outwards and
towards the rear part of the vehicle at the same
time to release the tongues.
Front central cover
- Remove the battery compartment cover and ex-
pansion tank compartment cover.
- Undo the two screws indicated.
- Unscrew the two screws indicated from the hel-
met compartment.
GP 800 i.e. Chassis
CHAS - 21
