Gilera GP 800 i.e. - Side Covers

To Next Page

To Previous Page

Side fairings

SIDE COVERS

Code Action Duration

1 004036 Frame cover - Replacement

2 004129 Rear fairing - Replacement

3 004068 Passenger handgrip - Re-

placement

4 004053 Spoiler - Replacement

Time GP 800 i.e.

TIME - 24
