Gilera GP 800 i.e. - Legshield

- Undo the five fixing screws and remove the head-
light frame plus the gasket.
CAUTION
UPON REFITTING, CHECK THE CORRECT PO-
SITION OF THE GASKET OF THE HEADLIGHT
FRAME.
- Undo the two screws indicated and take out the
front headlight assembly from its seat.
- Remove it once the connector has been discon-
nected.
Legshield
- Remove the windshield together with the brack-
ets.
- Remove the rear-view mirrors.
- Remove the headlight assembly.
- Undo the two screws indicated and remove the
front shield upper part.
GP 800 i.e. Chassis
CHAS - 5
