Gilera GP 800 i.e. - Page 358

- Undo the seven screws indicated.
- Undo the two screws indicated on both sides of
the wheel housing.
- Working on both sides, remove the Gilera clip-on
badge and undo the screw underneath.
- Remove the battery compartment cover and the
cover of the expansion tank cap.
- Undo the two screws indicated on both sides and
remove side fairings.
Chassis GP 800 i.e.
CHAS - 6
