Legshield spoiler

FRONT SHIELD

Code Action Duration

1 004021 Shield upper section - Re-

placement

2 004064 Front shield - Replacement

3 004020 Headlight frame - Replace-

ment

4 004085 Fairing (1) - Replacement

GP 800 i.e. Time

TIME - 23
