- Remove the radiator by releasing it from its fit-
tings.
- To remove the electric fan, first remove the radi-
ator and afterwards undo the three screws indica-
ted.
Rear
Remove the four fixing screws of the cover and
release it from the two leverages.
Handles and top side fairings
- These operations are described once but apply
to both vehicle fairings.
- Remove the rear central cover.
- Undo the three screws indicated to remove the
passenger grab handles.
- Undo the screws indicated and remove the li-
cense plate holder cover.
Chassis GP 800 i.e.
CHAS - 20
