PARKING BRAKE CONTROL REMOVAL
- Remove the shield back plate.
- Undo the four fixing screws and remove the
transmission cable.
BRAKE PAD REPLACEMENT
- Remove the brake calliper.
- Unscrew the two retaining pins and slide off the
pads.
- To refit, carry out the previous operations but in
reverse order.
Locking torques (N*m)
Pin fixing parking brake pads 15 ÷ 20
Braking system GP 800 i.e.
BRAK SYS - 20
