Gilera GP 800 i.e. - Front Support Service; Rear Support Service

REAR SUPPORT SERVICE
- Undo the two nuts indicated and collect the wash-
ers.
- Remove the link rods.
- Slide off the pin.
- Check the silent-block and the Teflon bushings
for wear; replace the components if necessary.
FRONT SUPPORT SERVICE
- Undo the indicated screw from both sides of the
vehicle and remove the supports.
- Check the silent-block for wear; replace the com-
ponents if necessary.
See also
Exhaust assy. Removal
Helmet bay
Air filter
Fuel tank
Fork
Engine from vehicle GP 800 i.e.
ENG VE - 14
