Gilera GP 800 i.e. - Footrest

- Remove the license plate support together with
the rear light unit.
- Undo the screw indicated and detach the rear
light unit from the license plate support
Footrest
- These operations are described once but apply
to both footrests.
- Remove the chassis side cover.
- Undo the two external screws.
- Undo the three screws from the internal side and
collect the washers.
See also
Side fairings
GP 800 i.e. Chassis
CHAS - 11
