Gilera GP 800 i.e. - Front Wheel Housing; Taillight Assy

Front wheel housing
- Remove the fork
- Undo the two screws indicated.
- Undo the two screws indicated.
- Disconnect the ambient temperature sensor.
- Release the throttle control transmissions and
the oil bleed pipe of the air filter from the clamps.
- Undo the screw fixing the electrical cable harness
clamp.
- Remove the front wheel housing together with the radiator cover.
Taillight assy.
- Undo the two screws indicated.
Chassis GP 800 i.e.
CHAS - 10
