Helmet bay

HELMET COMPARTMENT

Code Action Duration

1 004016 Helmet compartment - Re-

placement

2 005026 Helmet compartment bulb -

Replacement

3 005027 Helmet compartment bulb

support - Replacement

4 004142 Plug socket - Replacement

GP 800 i.e. Time

TIME - 45
