FRONT TURN INDICATORS INDICATOR LIGHTS

Code Action Duration

1 005067 Front direction indicator bulb

- Replacement

2 005012 Front direction indicators -

Replacement

3 005002 Front light - Replacement

4 005008 Light bulbs - Replacement

Rear lights

GP 800 i.e. Time

TIME - 35
