Front suspension

FRONT SUSPENSION

Code Action Duration

1 003010 Front suspension - Service

2 003112 Central steering tube - re-

placement

3 003107 Sliding stems - replacement

4 003002 Steering fifth wheel - Re-

placement

5 331352 Fork service

GP 800 i.e. Time

TIME - 47
