Gilera GP 800 i.e. - End Gear; Pinion Unit Shaft Bearing Removal

End gear
PINION UNIT SHAFT BEARING REMOVAL
- The toothed wheel (pinion unit shaft) rotates on
two bearings located on both crankcase halves. To
replace, proceed as follows.
- Transmission-side crankcase half:
- Remove the driven pulley shaft axle and the
toothed wheel.
- Acting on the specific tool, take out the bearing.
Specific tooling
001467Y006 Pliers to extract 20 mm bearings
001467Y035 Belle for OD 47-mm bearings
GP 800 i.e. Engine
ENG - 29
