Gilera GP 800 i.e. - Final Gear Assy; Final Reduction Gear Assembly

To Next Page

To Previous Page

Final gear assy.

FINAL REDUCTION GEAR ASSEMBLY

Code Action Duration

1 001195 Toothed wheel - Replac.

2 001196 Driven pulley shaft - Replac.

3 001190 Oil sealing casing - Replac.

Time GP 800 i.e.

TIME - 12
