Gilera GP 800 i.e. - Page 342

- Fasten the sheath to the chassis with a strap.
- Fasten the pipes to the chassis with a strap.
- Fasten the pipe to the clip.
- Fasten the pipe to the rear fork with the two clips.
Locking torques (N*m)
Nut fixing rear brake pipe retaining clip 11 ÷ 13
Braking system GP 800 i.e.
BRAK SYS - 18
