Gilera GP 800 i.e. - Page 281

Intake air temperature sensor
AIR TEMPERATURE SENSOR CONNECTOR
1. Control unit (White-Grey)
2. Control unit negative (Sky Blue-Green)
INTAKE AIR TEMPERATURE SENSOR
-10° = 9600 Ohm
0° = 5900 Ohm
+10° = 3800 Ohm
+20° = 2500 Ohm
-30° = 1700 Ohm
With the switch set to "ON", check if there is 5V voltage between pins 1 and 2 of the sensor connector
Check the continuity between pin 1 of the sensor connector and pin 14 of the engine connector control
unit.
GP 800 i.e. Injection
INJEC - 27
