- Remove the stem dust guard with a screwdriver.
- Remove the circlip retaining the oil seal.
- Pull out the stem with force to the end of stroke.
N.B.
THE STEM HAS A SLIDING BUSHING LOCA-
TED IN THE UPPER PART. WHEN THE STEM
IS BEING REMOVED, THE LOWER BUSHING
WORKS AS AN EXTRACTOR AGAINST THE
UPPER BUSHING, THE WASHER AND THE OIL
SEAL ON THE FORK LEG.
GP 800 i.e. Suspensions
SUSP - 11
