- Fit the seeger ring.
- Pull out the rear shock absorber silent-block with
a hydraulic press
- Similarly to the removal operations, drive a new
silent-block after heating with the specific tool.
Specific tooling
020151Y Air heater
- Undo the three fixing screws to replace the chain
stop slider.
- Upon fitting, tighten the three screws to the pre-
scribed torque.
Locking torques (N*m)
Screw fixing chain stop slider - fork 5 ÷ 7
GP 800 i.e. Suspensions
SUSP - 33
