Gilera GP 800 i.e.

To Next Page

To Previous Page

Stores code Description

020648Y Single battery charger

002465Y Pliers for circlips

020621Y HV cable extraction adaptor

020330Y Stroboscopic light for timing con-

trol

020335Y Magnetic support for dial gauge

GP 800 i.e. Tooling

TOOL - 7
