To access the air filter:
- Tip the saddle forwards, undo the five screws
«A» and remove cover «B».
- Remove the battery compartment access cover
«C» by undoing the four screws «D ».
- Remove the access cover to the cap of expan-
sion tank «E» by undoing the four screws «F».
- Undo the two screws «G».
- Remove the central cover «H» holding it as
shown in the figure and pulling it towards the rear
part of the vehicle.
GP 800 i.e. Maintenance
MAIN - 7
