9. 1A diode
10. Resistance 120 Ohm - 2W
11. Engine stop switch
12. 40A fuse
13. Voltage regulator
14. Main fuses
15. Main relay
16. Key switch contacts
17. Start-up remote control switch relay
18. Start-up maintenance relay
19. 1A diode
21. Auxiliary fuses
22. 12V - 14Ah battery
23. Starter motor
24. Start-up remote control switch
25. Starter button
26. Resistance 120 Ohm - 2W
27. 1A diode
28. 1A diode
35. Stop button on rear brake
36. Stop button on front brake
42. Rear light
A. Stop light LEDs
48. Instrument panel
54. Electronic ignition device (Vehicle connector)
Electrical system GP 800 i.e.
