Grandstream Networks UCM63 Series User Manual

P a g e | 149
UCM630X Series User Manual
Version 1.0.2.25
 Delete selected extensions
Select the checkbox for the extension(s). Then click on "Delete " to delete the extension(s).
Export Extensions
The extensions configured on the UCM630X can be exported to csv format file with selected technology "SIP",
"IAX" or "FXS". Click on "Export Extensions" button and select technology in the prompt below.
Figure 79: Export Extensions
The exported csv file can serve as a template for users to fill in desired extension information to be imported to
the UCM630X.
Import Extensions
The capability to import extensions to the UCM630X provides users flexibility to batch add extensions with similar
or different configuration quickly into the PBX system.
1. Export extension csv file from the UCM630X by clicking on "Export Extensions" button.
2. Fill up the extension information you would like in the exported csv template.
3. Click on "Import Extensions" button. The following dialog will be prompted.
Figure 80: Import Extensions
