P a g e | 402
UCM630X Series User Manual
Version 1.0.2.25
The page where the operation is made. For example, login, logout, delete user, create
trunk and etc.
Click on to view the options and values configured by this operation.
Allows users to add notes and remarks to each operation
User could also filter the operation logs by time condition, IP address and/or username. Configure these
conditions and then click on ”Display Filter”.
Figure 296: Operation Logs Filter
The above figure shows an example that operations made by user “support” on device with IP 192.168.40.173
from 2014-11-01 00:00 to 2014-11-06 15:38 are filtered out and displayed.
To delete operation logs, users can perform filtering first and then click on to delete
the filtered result of operation logs. Or users can click on to delete all operation logs at once.
Upgrading
The UCM630X can be upgraded to a new firmware version locally. And in order to do that, please follow the
below steps:
1. Download the latest UCM630X firmware file from the following link and save it in your PC.
http://www.grandstream.com/support/firmware
2. Log in the Web GUI as administrator in the PC.
