P a g e | 159

UCM630X Series User Manual

Version 1.0.2.25

Multiple Registrations per Extension

UCM630X supports multiple registrations per extension so that users can use the same extension on devices in

different locations.

Figure 87: Multiple Registrations per Extension

This feature can be enabled by configuring option “Concurrent Registrations” under Web

GUIExtension/TrunkEdit Extension. The default value is set to 1 for security purpose. Maximum is 10.

Figure 88: Extension - Concurrent Registration
