UCM630X Series User Manual
Version 1.0.2.25
Remote Extension in Ring Group
Remote extensions from the peer trunk of a remote UCM630X can be included in the ring group with local
extension. An example of Ring Group with peer extensions is presented in the following:
1. Creating SIP Peer Trunk between both UCM630X _A and UCM630X _B. SIP Trunk can be found under
Web GUIExtension/TrunkVoIP Trunks. Also, please configure their Inbound/Outbound routes
accordingly.
2. Click edit button in the menu , and check if Sync LDAP Enable is selected, this option will allow
UCM630X_A update remote LDAP server automatically from peer UCM630X _B. In addition, Sync LDAP
Password must match for UCM630X _A and UCM630X _B to sync LDAP contact automatically. Port number
can be anything between 0~65535, and use the outbound rule created in step 1 for the LDAP Outbound
Rule option.
Figure 154: Sync LDAP Server option
3. In case if LDAP server does not sync automatically, user can manually sync LDAP server. Under VoIP
Trunks page, click sync button shown in the following figure to manually sync LDAP contacts from peer
UCM630X.
Figure 155: Manually Sync LDAP Server
4. Under Ring Groups setting page, click “Add”. Ring Groups can be found under Web GUICall
FeaturesRing Groups.
