UCM630X Series User Manual
Version 1.0.2.25
IAX SETTINGS
The UCM630X IAX global settings can be accessed via Web GUIPBX SettingsIAX Settings.
IAX Settings/General
Table 111: IAX Settings/General
Bind Port
Configure the port number that the IAX2 will be allowed to listen to. The default
setting is 4569.
Bind IPv4 Address
Force IAX2 to bind to a specific address instead of all addresses.
Bind IPv6 address
Configure the IPv6 address to bind to. "[::]" means to bind to all IP addresses.
IAX1 Compatibility
Select to configure IAX1 compatibility. The default setting is "No".
No Checksums
If selected, UDP checksums will be disabled and no checksums will be
calculated/checked on systems supporting this feature. The default setting is
"No".
Delay Reject
If enabled, the IAX2 will delay the rejection of calls to avoid DOS. The default
setting is "No".
ADSI
Select to enable ADSI phone compatibility. The default setting is "No".
Music On Hold
Interpret
Specify which Music On Hold class this channel would like to listen to when being
put on hold. This music class is only effective if this channel has no music class
configured and the bridged channel putting the call on hold has no "Music On
Hold Suggest" setting.
Music On Hold
Suggest
Specify which Music On Hold class to suggest to the bridged channel when
putting the call on hold.
Bandwidth
Configure the bandwidth for IAX settings. The default setting is "Low".
IAX Settings/Registration
Table 112: IAX Settings/Registration
IAX Registration Options
Min Reg Expire
Configure the minimum period (in seconds) of registration. The default setting is
60.
Max Reg Expire
Configure the maximum period (in seconds) of registration. The default setting is
3600.
IAX Thread Count
Configure the number of IAX helper threads. The default setting is 10.
IAX Max Thread Count
Configure the maximum number of IAX threads allowed. The default is 100.
