Grandstream Networks UCM63 Series User Manual

P a g e | 38
UCM630X Series User Manual
Version 1.0.2.25
 Hardware Testing
Select Test SVIP to verify hardware connections within the device. The
result will display on the LCD when the test is complete.
Web Info
 Protocol: Web access protocol (HTTP/ HTTPS). HTTPS is used by default.
 Port: Web access port number, which is 8089 by default.
SSH Switch
 Enable SSH
 Disable SSH
SSH access is disabled by default
Use the LED Indicators
The UCM6301/6302 has LED indicators on the network port to display connection status and the following picture
shows the other ports status.
Figure 10: Ports Status
The UCM6304/6308 has LED indicators in the front to display connection status. The following table shows the
status definitions.
Table 4: UCM6304/6308 LED Indicators
LED Indicator
LED Status
Power 1/Power 2
PoE
LAN
WAN
USB
SD
FXS ports
FXO ports
Solid: Connected
Fast Blinking: Data Transferring
Slow Blinking: Trying to connect
OFF: Not Connected
