P a g e | 43
UCM630X Series User Manual
Version 1.0.2.25
SYSTEM SETTINGS
This section will explain the available system-wide parameters and configuration options on the UCM630X
series. This includes settings for the following items: HTTP server, network, OpenVPN, DDNS, LDAP server and
email server.
HTTP Server
The UCM630X's embedded web server responds to HTTPS GET/POST requests and allows users to configure
the UCM via web browsers such as Microsoft IE, Mozilla Firefox, and Google Chrome. By default, users can
access the UCM by just typing its IP address into a browser address bar. The browser will automatically be
redirected to HTTPS using port 8089. For example, typing in "192.168.40.50" into the address bar will redirect
the browser to "https://192.168.40.50:8089". This behavior can be changed in the System SettingsHTTP
Server page.
Table 5: HTTP Server Settings
Toggles automatic redirection to UCM's web portal from port 80. If
disabled, users will need to manually add the UCM's configured HTTPS
port to the server address when accessing the UCM web portal via
browser. Default is "Enabled".
Specifies the port number used to access the UCM HTTP server. Default
is "8089".
Enable IP Address Whitelist
If enabled, only the server addresses in whitelist will be able to access the
UCM's web portal. It is highly recommended to add the IP address
currently used to access the UCM web page before enabling this option.
Default is "Disabled".
List of addresses that can access the UCM web portal.
Ex: 192.168.6.233 / 255.255.255.255
Configure a URL and port (optional) used to access the UCM web portal
or a public link to the video conference room if the UCM is behind NAT.
Selects the method of acquiring SSL certificates for the UCM web server.
Two methods are currently available:
Upload Certificate: Upload the appropriate files from one's own PC.
Request Certificate: Enter the domain for which to request a
certificate for from Let's Encrypt.
To Next Page
