UCM630X Series User Manual
Version 1.0.2.25
Table 7: UCM630X Network Settings802.1X
802.1X Mode
Select 802.1X mode. The default setting is "Disable". The supported 802.1X mode
are:
 EAP-MD5
 EAP-TLS
 EAP-PEAPv0/MSCHAPv2
Identity
Enter 802.1X mode Identity information.
MD5 Password
Enter 802.1X mode MD5 password information.
802.1X CA Certificate
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
The UCM630X provides users static routing capability that allows the device to use manually configured routes,
rather than information only from dynamic routing or gateway configured in the UCM630X Web GUISystem
SettingsNetwork SettingsBasic Settings to forward traffic. It can be used to define a route when no other
routes are available or necessary, or used in complementary with existing routing on the UCM630X as a failover
backup, etc.
 Click on “Add IPv4 Static Route” to create a new IPv4 static route or click on ”Add IPv6 Static Route” to
create a new IPv6 static route. The configuration parameters are listed in the table below.
 Once added, users can select to edit the static route.
 Select to delete the static route.
Table 8: UCM630X Network SettingsStatic Routes
Destination
Configure the destination IPv4 address or the destination IPv6 subnet for the
UCM630X to reach using the static route.
Example:
IPv4 address - 192.168.66.4
IPv6 subnet - 2001:740:D::1/64
Subnet Mask
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
