UCM630X Series User Manual
Version 1.0.2.25
Keep Alive Interval
Specify how often the phone will send a blank UDP packet to the SIP server
in order to keep the “ping hole” on the NAT router to open. Valid range is
10-160.
Register Expiration
Specify the Register Expiration.
Local SIP Port
Configure Local SIP Port.
Local RTP Port
Configure Local RTP Port.
Auto On-Hook Timer(s)
Configure Auto On-Hook Timer(s).
Ring Timeout
Configure Ring Timeout.
SIP Transport
Select either UDP, TCP or TLS/TCP as SIP transport protocol.
SIP Proxy Compatibility
Mode
Select either to disable or enable SIP Proxy Compatibility Mode.
Unregister On Reboot
Select either to disable or enable Unregister On Reboot.
Whitelist
Whitelist
Select either to enable or disable Whitelist
SIP Phone Number Whitelist
Configure the SIP Phone Number Whitelist.
Table 29: Global Policy Parameters – Customization
Wallpaper
Screen Resolution 1024 x
600
Check this option if the SIP end device shall use 1024 x 600 resolution for
the LCD screen wallpaper.
 Source
Configure the location where wallpapers are stored.
 File
If “URL” is selected as source, specify the URL of the wallpaper file. If
“Local UCM Server” is selected as source, click to upload wallpaper
file to the UCM630X.
Screen Resolution 800 x 400
Check this option if the SIP end device shall use 800 x 400 resolution for
the LCD screen wallpaper.
 Source
Configure the location where wallpapers are stored.
 File
If “URL” is selected as source, specify the URL of the wallpaper file. If
“Local UCM Server” is selected as source, click to upload wallpaper
file to the UCM630X.
Screen Resolution 480 x 272
Check this option if the SIP end device shall use 480 x 272 resolution for
the LCD screen wallpaper.
 Source
