UCM630X Series User Manual
Version 1.0.2.25
 Voicemail
 Conference Room
 Call Queue
 Ring Group
 Paging/Intercom
 Voicemail Group
 DISA
 IVR
 By DID
When "By DID" is used, the UCM will look for the destination based on
the number dialed, which could be local extensions, conference, call
queue, ring group, paging/intercom group, IVR and voicemail groups as
configured in "DID destination". If the dialed number matches the DID
pattern, the call will be allowed to go through.
Configure the number of digits to be stripped in "Strip" option.
 Dial By Name
 External Number
 Callback
Inbound Route: Prepend Example
UCM630X now allows user to prepend digits to an inbound DID pattern, with strip taking precedence over
prepend. With the ability to prepend digits in inbound route DID pattern, user no longer needs to create multiple
routes for the same trunk to route calls to different extensions. The following example demonstrates the process:
1. If Trunk provides a DID pattern of 18005251163.
2. If Strip is set to 8, UCM630X will strip the first 8 digits.
3. If Prepend is set to 2, UCM630X will then prepend a 2 to the stripped number, now the number become
2163.
4. UCM630X will now forward the incoming call to extension 2163.
