P a g e | 185
UCM630X Series User Manual
Version 1.0.2.25
SLA STATION
The UCM630X supports SLA that allows mapping the key with LED on a multi-line phone to different external
lines. When there is an incoming call and the phone starts to ring, the LED on the key will flash in red and the
call can be picked up by pressing this key. This allows users to know if the line is occupied or not. The SLA
function on the UCM630X is like BLF but SLA is used to monitor external line i.e., analog trunk on the UCM630X.
Users could configure the phone with BLF mode on the MPK to monitor the analog trunk status or press the line
key pick up call from the analog trunk on the UCM630X.
Create/Edit SLA Station
SLA Station can be configured on Web GUIExtension/TrunkSLA Station.
Figure 100: SLA Station
Click on to add an SLA Station.
Click on to edit the SLA Station. The following table shows the SLA Station configuration parameters.
Click on to delete the SLA Station.
Table 61: SLA Station Configuration Parameters
Configure a name to identify the SLA Station.
Specify a SIP extension as a station that will be using SLA.
Existing Analog Trunks with SLA Mode enabled will be listed here.
Select a trunk for this SLA from the Available SLA Trunks list. Click on
to arrange the order. If there are multiple trunks selected, when there are
calls on those trunks at the same time, pressing the LINE key on the phone will
pick up the call on the first trunk here.
Configure the time (in seconds) to ring the station before the call is considered
unanswered. No timeout is set by default. If set to 0, there will be no timeout.
Configure the time (in seconds) for delay before ringing the station when a call
