UCM630X Series User Manual
Version 1.0.2.25
the global ring timeout setting under Web GUIPBX SettingsVoice
PromptCustom Prompt: General Preference. The valid range is between 5 seconds
and 600 seconds.
Note: If the end point also has a ring timeout configured, the actual ring timeout used
is the shortest time set by either device.
Auto Record
Enable automatic recording for the calls using this extension. The default setting is
disabled. The recordings can be accessed under Web GUICDRRecording Files.
Skip Trunk Auth
 If set to “yes”, users can skip entering the password when making outbound calls.
 If set to “By Time”, users can skip entering the password when making outbound
calls during the selected time condition.
 If set to “No”, users will be asked to enter the password when making outbound
calls.
Time Condition for
Skip Trunk Auth
If ‘Skip Trunk Auth’ is set to ‘By Time’, select a time condition during which users can
skip entering password when making outbound calls.
Dial Trunk
Password
Configure personal password when making outbound calls via trunk.
Enable LDAP
If enabled, the extension will be added to LDAP Phonebook PBX list.
Enable WebRTC
Support
Enable registration and call from WebRTC.
Music On Hold
Specify which Music On Hold class to suggest to the bridged channel when putting
them on hold.
Call Duration Limit
The maximum duration of call-blocking.
Maximum Call
Duration
The maximum call duration (in seconds). The default value 0 means no limit.
Batch Extension Resetting Functionality
Users can select multiple extensions and reset their settings to default by pressing the reset button
and confirm the reset functionality. Once done, all settings in Basic Settings page will be restored to default
values with the exception of Concurrent Registrations. User voicemail password will be reset to Random
Password. User voicemail prompts and recordings will be deleted. User Management settings will also be
restored to default with the exception of usernames and custom privileges
Search and Edit Extension
All the UCM630X extensions are listed under Web GUIExtension/TrunkExtensions, with status,
Extension, CallerID Name, Technology (SIP, IAX and FXS), IP and Port. Each extension has a checkbox for
users to "Edit" or "Delete". Also, options "Edit” , "Reboot" and "Delete" are available per extension.
User can search an extension by specifying the extension number to find an extension quickly.
