UCM630X Series User Manual
Version 1.0.2.25
DTMF Mode
Select DTMF mode to send DTMF. The default setting is RFC4733. If "Info" is
selected, SIP INFO message will be used. If "Inband" is selected, 64-kbit codec
PCMU and PCMA are required. When "Auto" is selected, "RFC4733" will be used
if offered, otherwise "Inband" will be used. The default setting is "RFC4733".
RTP Timeout
During an active call, if there is no RTP activity within the timeout (in seconds),
the call will be terminated. The default setting is no timeout.
Note: This setting does not apply to calls on hold.
RTP Hold Timeout
When the call is on hold, if there is no RTP activity within the timeout (in seconds),
the call will be terminated. This value of RTP Hold Timeout should be larger than
RTP Timeout. The default setting is no timeout.
RTP Keep-alive
This feature can be used to avoid abnormal call drop when the remote provider
requires RTP traffic during proceeding.
For example, when the call goes into voicemail and there is no RTP traffic sent
out from UCM, configuring this option can avoid voicemail drop.
When configured, RTP keep-alive packet will be sent to remote party at the
configured interval. If set to 0, RTP keep-alive is disabled.
100rel
Configure the 100rel setting on UCM630X. The default setting is “Yes”.
Trust Remote Party ID
Configure whether the Remote-Party-ID should be trusted. The default setting is
"No".
Send Remote Party ID
Configure whether the Remote-Party-ID should be sent or not. The default
setting is "No".
Generate In-Band
Ringing
Configure whether the UCM630X should generate Inband ringing or not. The
default setting is "Never".
 Yes: The UCM630X will send 180 Ringing followed by 183 Session
Progress and in-band audio.
 No: The UCM630X will send 180 Ringing if 183 Session Progress has not
been sent yet. If audio path is established already with 183 then send in-
band ringing.
 Never: Whenever ringing occurs, the UCM630X will send 180 Ringing as
long as 200OK has not been set yet. Inband ringing will not be generated
even the end point device is not working properly.
Server User Agent
Configure the user agent string for the UCM630X.
Send Compact SIP
Headers
If enabled, compact SIP headers will be sent. The default setting is "No".
Passthrough PAI
Header
Passthrough PAI Header
