UCM630X Series User Manual
Version 1.0.2.25
Subnet Mask
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Gateway IP
Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
DNS Server 1
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
DNS Server 2
Enter the DNS server 2 address for static IP settings.
Username
Enter the username to connect via PPPoE.
Password
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
LAN 1 / LAN 2 (when Method is set to "Dual")
Default
Interface
If "Dual" is selected as "Method", users will need assign the default interface to be LAN 1
(mapped to UCM6302 WAN port) or LAN 2 (mapped to UCM6302 LAN port) and then
configure network settings for LAN 1/LAN 2. The default interface is LAN 2.
IP Method
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
IP Address
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Subnet Mask
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Gateway IP
Enter the gateway IP address for static IP settings when the port is assigned as default
interface. The default setting is 0.0.0.0.
DNS Server 1
Enter the DNS server 1 address for static IP settings.
The default setting is 0.0.0.0.
DNS Server 2
Enter the DNS server 2 address for static IP settings.
Username
Enter the username to connect via PPPoE.
Password
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port.
The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
IPv6 Address
WAN (when "Method" is set to "Route")
IP Method
Select Auto or Static. The default setting is Auto
