UCM630X Series User Manual
Version 1.0.2.25
To configure Grandstream IP phones as the LDAP clients for UCM, please refer to the following example:
 Server Address: The IP address or domain name of the UCM
 Base DN: dc=pbx,dc=com
 Username: Please leave this field empty
 Password: Please leave this field empty
 LDAP Name Attribute: CallerIDName Email Department FirstName LastName
 LDAP Number Attribute: AccountNumber MobileNumber HomeNumber Fax
 LDAP Number Filter: (AccountNumber=%)
 LDAP Name Filter: (CallerIDName=%)
 LDAP Display Name: AccountNumber CallerIDName
 LDAP Version: If existed, please select LDAP Version 3
 Port: 389
The following figure shows the configuration information on a Grandstream GXP2170 to successfully use the
LDAP server as configured in [Figure 33: LDAP Server Configurations].
