Grandstream Networks UCM63 Series User Manual

P a g e | 95
UCM630X Series User Manual
Version 1.0.2.25
Password
Configure the bind “Password” for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
Number Filter
Configure the filter used for number lookups. Please refer to user manual
for more details.
Name Filter
Configure the filter used for name lookups. Please refer to user manual for
more details.
Version
Select the protocol version for the phone to send the bind requests. The
default value is 3.
Name Attribute
Specify the “name” attributes of each record which are returned in the
LDAP search result.
Example:
gn
cn sn description
Number Attribute
Specify the “number” attributes of each record which are returned in the
LDAP search result.
Example:
telephoneNumber
telephoneNumber Mobile
Display Name
Configure the entry information to be shown on phone’s LCD. Up to 3 fields
can be displayed.
Example:
%cn %sn %telephoneNumber
Max Hits
Specify the maximum number of results to be returned by the LDAP server.
Valid range is 1 to 3000. The default value is 50.
Search Timeout
Specify the interval (in seconds) for the server to process the request and
client waits for server to return. Valid range is 0 to 180. Default value is 30.
Sort Results
Specify whether the searching result is sorted or not. Default setting is No.
Incoming Calls
Configure to enable LDAP number searching when receiving calls. The
default setting is No.
Outgoing Calls
Configure to enable LDAP number searching when making calls. The
default setting is No.
Lookup Display Name
Configures the display name when LDAP looks up the name for incoming
call or outgoing call.
It must be a subset of the LDAP Name Attributes.
XML Phonebook
Phonebook XML Server
Select the source of the phonebook XML server.
 Disable
Disable phonebook XML downloading.
