ADVANCED MEASUREMENT
107
Measure Percent
Press the Shift + Math key to activate Math
setting menu as the following figure shown.
Further press the F1 (Function) key to enter
the Math Function menu as the figure shown
below.
Press F6 (More 1/2) key to enter the next
page followed by pressing the F2 (Percent)
key. Percent function will be activated as the
following figure shown.
Indicator Percent On
The Measured Percent Value
F3 (REF %)
key to set
reference
%
Press the F3 (REF %) key to enter the
Percent REF % menu. First use the functions
keys to determine the unit, which may vary by
different measure modes. Then use the
Left/Right arrow keys to move cursor and
scroll the Knob key or press Number keys to
enter the desired value. See the figure below.
To Next Page
