GW Instek GDM-906 Series User Manual

GDM-906X Series User Manual
56
Thermocouple Sensor Type
Background
The GDM-9060/9061 accepts thermocouple inputs and
calculates the temperature from the voltage difference of
two dissimilar metals. Thermocouple sensor type is one
of the main factors to be considered.
Parameter
Thermocouple
Sensor Type
Measurement
Range
Resolution
J
-210 to +1200˚C
0.002 °C
K
-200 to +1372˚C
0.002 °C
N
-200 to +1300˚C
0.003 °C
R
-50 to +1768˚C
0.01 °C
S
-50 to +1768˚C
0.01 °C
T
-200 to +400°C
0.002 °C
B
+250 to +1820˚C
0.01 °C
E
-200 to +1000°C
0.002 °C
Reference Junction Temperature (SIM Temperature)
Background
(Thermocouple
only)
When a thermocouple is connected to the
GDM-9060/9061, the temperature difference between
the thermocouple lead and the GDM-9060/9061 input
terminal should be taken into account and be cancelled
out; otherwise an erroneous temperature might be added.
The value of the reference junction temperature should
be determined by the user.
Type
Range
Resolution
SIM
(simulated)
-20°C ~ +80°C
0.01°C
The terminal temperature is manually defined by user.
Default value: Auto
