GW Instek GDM-906 Series User Manual

GDM-906X Series User Manual
362
Considerations
or period of an input following a dc offset voltage change.
The input blocking RC time constant must be allowed to
fully settle (up to 1 sec) before the most accurate
measurements are possible.
Measurement
Considerations
All frequency counters are susceptible to error when
measuring low-voltage, low-frequency signals.
Shielding inputs from external noise pickup is critical for
minimizing measurement errors.
Operating Characteristics
Function
Gate Time
Digits
Frequency,
Period
1 s
6 ½
100 ms
5 ½
10 ms
4 ½
[1]. This specification will be available after 60 minutes of warm-up and
sine wave input, unless stated otherwise. This specification applies to
1s gate time.
[2]. This specification is available when both sine wave and square wave
input ≥ 100 mV. For the input of 10 mV to 100 mV, the % of reading
error needs to be multiplied by 10 times.
[3]. The amplitude range is from 10% to 120% and is lower than 750 ACV.
[4]. The input ≥ 60 mV, for 300 k ~ 1 MHz, within 100mV range.
Temperature Characteristics
[1]
(Exclusive of probe errors)
RTD (Accuracy based on PT100):
(100 Ω platinum [PT100], D100, F100, PT385, PT3916, or user type)
Range
Resolution
1 Year (23 °C ±5 °C)
Temperature Coefficient
0°-18 °C & 28°-55 °C
-200 °C~ -100 °C
0.001 °C
0.09 °C
0.004 °C / °C
-100 °C~-20 °C
0.001 °C
0.08 °C
0.005 °C / °C
-20 °C~20 °C
0.001 °C
0.06 °C
0.005 °C / °C
20 °C~100 °C
0.001 °C
0.08 °C
0.005 °C / °C
100 °C~300 °C
0.001 °C
0.12 °C
0.007 °C / °C
300 °C~600 °C
0.001 °C
0.22 °C
0.009 °C / °C
Thermocouples (Accuracy based on ITS-90):
Type
Range
Resolution
90 Day/1 Year
(23 °C±5 °C)
Temperature Coefficient
0°-18 °C & 28°-55 °C
E
-200 to +1000 °C
0.002 °C
0.2 °C
0.03 °C / °C
J
-210 to +1200 ˚C
0.002 °C
0.2 °C
0.03 °C / °C
