GDM-906X Series User Manual
120
Application: 4094 / User Mode
Overview
4094 and User mode can only used when using a remote
control interface. Likewise this mode can only be enabled or
disabled via remote control. Please see the digital I/O
commands on page 272 for full usage details.
User Mode – IO (Output) Mode
Overview
It is the mode utilizing output as general IO (Output) usage
with up to 4 pins available for use simultaneously. Refer to
the following introductions along with diagrams for more
details. Please see the digital I/O commands on page 272 for
full usage details.
Related
Commands
DIG:INT:MODE IO (switch to IO mode)
DIG:INT:DATA:SET 0,1,1,0
=> OUT1(Pin5) : +0V
OUT2(Pin6) : +5V
OUT3(Pin7) : +5V
OUT4(Pin8) : +0V
Pin
Assignment
Pin No
User Mode
Description
1
VCC Out
Option(Vcc:+5V)
2
Flyback Diode
No Use
3
Digital Ground
GND
5
OUT1
Use
6
OUT2
Use
7
OUT3
Use
8
OUT4
Use
