GDM-906X Series User Manual
102
MX+B Measurement
Press the Shift + Math key to activate Math
setting menu as the following figure shown.
Further press the F1 (Function) key to enter the
Math Function menu as the figure shown
below.
Press F5 (MX+B) key to enable the MX+B
function. The screen, after activation, will appear
as figure below.
Indicator MX+B On
MX+B
Calculation
F3 (M
Value) key
to set the
factor M
Press the F3 (M Value) key to enter the MX+B
M Value menu. First use function keys to
decide unit value, which may vary by different
measurements. Then use the Left/Right arrow
keys to move cursor and scroll the Knob key or
press Number keys to enter the desired value.
See the figure below.
Press the F6 (Enter) key or the Knob key until
click to confirm the input M value.
To Next Page
