GW Instek GDM-906 Series User Manual

BASIC MEASUREMENT
45
F3 (BeepVol) key
to select the Vol
Press the F2 ~ F4 key to select the volume level
or press the F1 key to set Beep volume off
Set Continuity Threshold
Background
The continuity threshold defines the maximum resistance
allowed in the DUT when testing the continuity.
Threshold Range
Threshold
1 to 1000Ω (Default Threshold:10Ω)
Resolution
1Ω
Procedure
Press the F4 key to enter the Threshold of
Continuity menu as the figure below shown.
Set the continuity threshold level.
1. Use the Left/Right arrow keys to move cursor
and scroll the Knob key or press Number
keys to enter the desired value.
2. Press the F6 (Enter) key or the Knob key until
click to confirm the threshold settings.
Display
