BASIC MEASUREMENT
31
Select Voltage Range
Auto range
To turn the automatic range selection
On/Off, press the Auto key.
Manual range
Press the “+” or the “-” key to select the
range. The Auto indicator turns to
indicating Manual range selection.
If the appropriate range is unknown,
select the highest range.
You can also press the F1 (Range) key to
select a range for the measurement.
Press the F1 ~ F6 key to select a desired
range for the voltage measurement.
Selection list
Range
Resolution
Full scale
100mV
0.1μV
119.9999mV
1V
1 μV
1.199999 V
10V
10 μV
11.99999 V
100V
100 μV
119.9999 V
750V (AC)
1mV
787.500 V
1000V (DC)
1mV
1050.000 V
Note
For more detailed parameters, see the specifications on
page 343.
